تفاصيل المنتج:
|
| حالة الآلة: | عمل سيامي | إجمالي وزن الجهاز: | 1500 كجم |
|---|---|---|---|
| نطاق حجم الإنتاج: | 1130*880 مللي متر | طريقة نقل الإنتاج: | النقل التلقائي إلى المعالج |
| الجهد االكهربى: | 220 فولت | سمك إخراج اللوحة: | 0.15-0.28 |
| إبراز: | 830nm Computer To Plate Machine,High Precision Computer To Plate Machine,Automatic thermal platesetter,High Precision Computer To Plate Machine,Automatic thermal platesetter |
||
| Model | Thermal | UV | ||||||||
| T824 | T832 | T848 | T864 | T8128 | U824 | U832 | U848 | U864 | U8128 | |
| NO.of lasers | 24 | 32 | 48 | 64 | 128 | 24 | 32 | 48 | 64 | 128 |
| Throughput(1130*800) | 13 | 18 | 23 | 28 | 45 | 13 | 18 | 23 | 28 | 45 |
| Max.Min.Format | MAX:1160*940 MIN:400*350 | MAX:1160*940 MIN:400*350 | ||||||||
| Laser source | 830nm | 405nm | ||||||||
| Resoiution | 2400DPI | |||||||||
| Loading system | Automatic,Semi-Auto(Optional Auto-loader) | |||||||||
| Plate requirement | CD. 0.15-0.4 (Thermal plate) | CD. 0.15-0.4 UV plate | ||||||||
| Interface | 1-bit Tiff interface and direct workflow driver,support CIP3/CIP4 | |||||||||
| Power | AC220V,50-60HZ 5.5KVA | |||||||||
| Work environment | Temperature:20-25℃,Humility:40%-80% | |||||||||
Applicable sheet model: 0.15 thickness -0.3 thickness.
Resolution: 2,400dpi or 1,200dpi optional 2,540dpi or 1,270dpi (variable resolution option: the highest precision can reach 12,800dpi in the circumferential direction)
Repeatability: ±0.01mm
Output interface: optical fiber interface
Environment: allowable temperature: 15-32℃, recommended temperature: 21-28℃, relative humidity: <70%
Applicable: CTP plate, CTCP plate and double layer CTP plate.
Different models of machines have different production times and speeds.
