تفاصيل المنتج:
|
| كيف تعمل الآلة: | عملية أوتوماتيكية بالكامل، | حالة الآلة: | نوع ملتصق أيضا آلة، ناقل حركة أوتوماتيكي |
|---|---|---|---|
| الطاقة الانتاجية القصوى: | 1180*950 | الجهد الآلي: | 220 فولت |
| اسم اللوحة: | لوحة CTP الحرارية | سماكة اللوحة: | 0.15-0.28 |
| إبراز: | Fully Automatic Thermal CTP Machine,Computer Plate Thermal CTP Machine,0.28mm thermal ctp systems,Computer Plate Thermal CTP Machine,0.28mm thermal ctp systems |
||
Before delivery, my engineer will do three detailed inspections, replace damaged parts, and give customers a different feeling. Let customers get the best.
Basic parameters of the machine:
Maximum production size: 1180*950
Minimum production size: 400*350mm
Applicable sheet model: 0.15 thickness -0.28 thickness.
Resolution: 2,400dpi or 1,200dpi optional 2,540dpi or 1,270dpi (variable resolution option: the highest precision can reach 12,800dpi in the circumferential direction)
Repeatability: ±0.01mm
Applicable: CTP plate, CTCP plate and double layer CTP plate.s
| T824 | T832 | T848 | T864 | T8128 | U824 | U832 | U848 | U864 | U8128 |
| 24 | 32 | 48 | 64 | 128 | 24 | 32 | 48 | 64 | 128 |
| 13 | 18 | 23 | 28 | 45 | 13 | 18 | 23 | 28 | 45 |
| MAX:1160*940 MIN:400*350 | MAX:1160*940 MIN:400*350 | ||||||||
| 830nm | 405nm | ||||||||
| 2400DPI | |||||||||
| Automatic,Semi-Auto(Optional Auto-loader) | |||||||||
| CD. 0.15-0.4 (Thermal plate) | CD. 0.15-0.4 UV plate | ||||||||
| 1-bit Tiff interface and direct workflow driver,support CIP3/CIP4 | |||||||||
| AC220V,50-60HZ 5.5KVA | |||||||||
| Temperature:20-25℃,Humility:40%-80% | |||||||||
